circuit using conditional operator (?).
고 45.31 MULTIPLEXER show. because tokes the ped for the Samen Tv Based on the examples explained above, Write a Verilog module mux8 for 8.1 multiplexer Circuit using conditional operator (29) as shown above. The 8:1 multiplexer has 8 inputs and 1 output, and all inputs and output are 4-bit wide. It selects one input among 8 inputs according to 3 select (s[2], [1], stop). For instance, if s[2], [1], stoj is 110 which is equal to decimal 6. then do will be selected in the figure below. As a result, yd6. 0 31 do dl - 82 d3 04 - ds d6 - d7 2 3 -4 Mux 8:1 Submission rules Write the solution on a paper (must be handwritten). Write your name surname and student id on the solution paper. We will collect the prelab works on papers) the first 10 minutes in the lab.
